3×2 H Centrifugal Heavy Duty Slurry Pump is 2 inch slurry pump designed for handling highly abrasive,high density slurries with excellent wear life while maintaining efficiency during the wear cycle providing the best total operating cost. This pump is 2 in slurry pump according to discharge size.

3×2 H Slurry Pump Wetted Parts

Liners – Hard metal liners are completely interchangeable with pressure molded elastomer. Elastomer seal rings back all liner joints. Easily replaceable liners are bolted, not glued, to the casing for positive attachment and east of maintenance.
Impeller – Hard metal and molded elastomer impellers are completely interchangeable. Front and rear shrouds have pump out vanes that reduce recirculation and seal contamination.

The pump can be used in many applications, such as Pipeline transport, High velocity hydraulic transport, Mineral processing, Coal prep, Cyclone feeds, Aggregate processing, Fine primary mill grinding, Chemical slurry service, Tailings, secondary grinding, Industrial processing, Pulp and paper, Food processing, Cracking operations, Ash handling.

2inch slurry pump with CV driven type

2inch slurry pump with CV driven type

2inch slurry pump with CV driven type

2inch slurry pump with CV driven type

2inch slurry pump with CV driven type

2inch slurry pump with CV driven type
